OLYMPIC

Used Olympic OMS36144-2 Hydraulic Lift Table

Machine Information

Capacity: 2,000 lbs, evenly distributed load
Platform: 36” x 144” smooth plate with 3 lanes of gravity roller conveyors
3 lanes x 39” BFP x 36” long with 1.9” diameter at 3” centers
and 6 removeable tube stops – sockets on side of platform
Base frame: 36” x 128”
Lowered height 18.75”
Raised height 48.75”
Travel 30”
Power pack internal 1 HP 110V / 1PH / 60 Hz
Controls: push button x 12 ft cable to hook on side of platform
Scissors Constructed from profile cut steel
Cylinder Solid ram style with hydraulic safety velocity fuse
Axle pins 100,000 PSI yield strength chrome shafting
Pivot points All with self lubricating bushings
Accordion bellows around base frame
4 swivel castors mounted underneath with 6” dia phenolic wheel sand floro lock on one end
Maintenance blocks
